◆ The air pressure is stable, more energy-saving, no impact on start-up,low noise, automatic sleep, reduced mechanical wear,extended motor life, reducedoperating costs, improvedpressure control accuracy, andincreased productivity.
| Model | QC-45G | QC-55G | QC-75G | QC-90G | QC-110G | QC-132G | QC-160G | |
| Air Flow/ Working Pressure | M³/Min/MPa | 7.7/0.8 | 9.5/0.8 | 12.6/0.8 | 16.0/0.8 | 20.0/0.8 | 23.1/0.8 | 27.0/0.8 |
| 7.0/1.0 | 8.5/1.0 | 11.8/1.0 | 13.8/1.0 | 17.3/1.0 | 20.1/1.0 | 25.0/1.0 | ||
| 5.8/1.3 | 7.1/1.3 | 9.8/1.3 | 12.4/1.3 | 14.8/1.3 | 18.1/1.3 | 22.5/1.3 | ||
| Compressed series | Single Stage | |||||||
| The environment temperature | ﹣5℃-+45℃ | |||||||
| Cooling way | Air cooling | |||||||
| Exhaust temperature | ℃ | 55℃ | ||||||
| Noise | dB（A) | 63±2 | 73±2 | 73±2 | 75±2 | 85±2 | ||
| Drive way | Dirict Drive | |||||||
| Power supply | D/PH/HZ | 380V/50HZ,220V/50HZ,220V/60HZ,415V,Custom Voltage | ||||||
| Rate of work | KW | 45 | 55 | 75 | 90 | 110 | 132 | 160 |
| Starting way | Y-▲start | |||||||
| Dimension(mm) | Length | 1340 | 1560 | 1700 | 1700 | 2000 | 2400 | |
| Width | 930 | 1100 | 1170 | 1170 | 1450 | 1500 | ||
| Highly | 1200 | 1450 | 1540 | 1540 | 1830 | 1970 | ||
| Weight | KG | 730 | 1120 | 1230 | 1280 | 1800 | 2000 | 3900 |
| Outlet pipe diameter | imch/mm | 1 1/2″ | 2″ | 2″ | 2-1/2″ | DN80 | ||
